CS-300/380/300S Gloss Meter

CS-300/380/300S Gloss Meter

CS-300 series glossometer comply with DIN 67530, ISO 2813, ASTM D 523, JIS z8741, BS 3900 part d5 and jjg696....

  • Fast Delievery
  • Quality Assurance
  • 24/7 Customer Service

CS-300/380/300S Gloss Meter

CS-300 series glossometer, with its classic smooth shape and comfortable grip, fits perfectly with the palm of your hand, so that you can not only use it easily, but also love it more; The slim body and large power can be measured 54300 times continuously, so that you have no worries about power and no distractions at work. Comply with DIN 67530, ISO 2813, ASTM D 523, JIS z8741, BS 3900 part d5 and jjg696.

CS-300 series gloss meter includes < strong > three models < / strong >, CS-300 is a 60 degree angle gloss meter, cs-380 is a 20 °, 60 ° and 85 ° gloss meter, and cs-300s is a 2 * 3mm microporous gloss meter


Features 蓝.jpg

Gloss measurement covering a variety of products

It is mainly used to measure the surface gloss of materials in spraying, plastic, printing, metal, ceramics, building materials, leather, paint and other industries

All kinds of experience begin with "accurate"; Precise and impressive


Affirmation of national metrology research institutions

The stability is 0.2gu, which is a little too stable

43200 stability tests ensure the stability of the measurement


Super long endurance, capable of measuring 50000 times continuously

3000mAh high-capacity rechargeable lithium battery is adopted to realize both thin body and large power. It can be measured 54300 times continuously, so that you can have no worry about power and concentrate on your work



CS-300/380/300S Protable  Gloss Meter

Model

CS-300

CS-380

CS-300S

Test angle

60°

20°60°85°

60°

Test light spot(mm)

60°:9*15

20°:10*10

60°:9*15

85°:5*38

60°:2*3

Test range

60°:0-1000GU

20°:0-2000GU;

60°:0-1000GU;

85°:0-160GU

60°:0-600GU

Stability

0-100:0.1GU;more than 100:1GU

Repeatability

0-100GU:0.2GU

100-2000GU:0.2%GU

0-100GU:0.2GU

100-2000GU:0.2%GU

0-100GU:0.2GU

100-600GU:0.2%GU

Test modes

Simple mode and statistical mode

Accuracy

Meet the requirements of JJG 696-2002 class I working glossometer

Test time

Less than 1s

Data storage

It can store 100 standard samples and 10000 samples

Size

165 * 51 * 77mm (L * w * h)

Weight

About 400g

Language

Chinese, English

Battery

3000mAh lithium battery

Interface

USB, Bluetooth (optional)

Working temperature

0-40℃

Humidity

Less than 85%, no condensation

Accessories



5V / 2A charger, USB data cable, manual,

CD (upper computer software)

Calibration standard board, national metrological certification



5V / 2A charger, USB data cable
Manual, software CD, calibration standard board

Purpose

Paint, ink, coating, electroplating, plastic electronics, hardware and other fields
